Introduction

Asguard is a real-time fraud detection engine designed for modern enterprises. It combines deterministic rule-based scoring with probabilistic AI analysis to provide accurate, explainable risk assessments for financial transactions.

The system is built with Go 1.25+ and follows clean architecture principles, ensuring maintainability, testability, and scalability. It exposes a RESTful API that can be integrated into existing payment flows, e-commerce platforms, or financial systems.

Key Features

• Hybrid Scoring: Combines rule-based and AI-powered analysis for optimal accuracy
• Biometric Face Verification: Optional microservice for extracting facial embeddings and comparing them to stored references
• Low Latency: Sub-200ms response times for rule-based scoring; AI escalation adds ~500ms
• Explainable: Every decision includes detailed reasoning and confidence scores
• Stateless: No persistent storage of sensitive transaction data
• BYOK: Bring Your Own Key model for AI integration ensures data privacy

Use Cases

• Real-time payment authorization
• High-value transaction verification
• Cross-border payment screening
• Account takeover detection
• Merchant risk assessment

Quick Start

Installation

Prerequisites

• Go 1.25 or later
• Git
• Groq API key (get one at console.groq.com)
• Docker & Docker Compose (highly recommended for the face service; requires dlib models)
• dlib model files (shape_predictor_5_face_landmarks.dat, dlib_face_recognition_resnet_model_v1.dat, mmod_human_face_detector.dat). Place them under ./models/ at the repo root.
• Docker (optional, for containerized deployment)

Clone and Setup

git clone https://github.com/org-cyber/asguard.git
cd asguard/backend
go mod download

Configuration

Create a .env file in the backend/ directory:

ASGUARD_API_KEY=your-secure-api-key-min-32-chars
GROQ_API_KEY=gsk_your_groq_api_key_here
PORT=8081
ENV=development

Running Locally

go run main.go

The server will start on http://localhost:8081. You should see:

2026/03/02 10:00:00 Starting Asguard server on :8081
2026/03/02 10:00:00 Environment: development
2026/03/02 10:00:00 Risk Engine: initialized
2026/03/02 10:00:00 AI Service: connected to Groq API

Verify Installation

curl http://localhost:8081/health

Expected response:

{
  "status": "asguard health running",
  "version": "1.0.0",
  "timestamp": "2026-03-02T10:00:00Z"
}

Architecture

Asguard follows a layered architecture pattern with clear separation of concerns. The system is designed to be stateless, allowing for horizontal scaling and simple deployment.

Beginning with version 1.1.0 the platform includes an optional **facial verification microservice** (`asguard-face`) that runs alongside the transaction engine. It is a lightweight Go service that exposes two endpoints—one for extracting 128‑dimensional embeddings from images, and another for comparing them. This allows you to build passwordless login, KYC onboarding, or transaction‑level biometric checks.

Request Lifecycle

Every transaction analysis request flows through the following stages:

1. Authentication Layer

The APIKeyAuth middleware validates the x-api-key header against the configured ASGUARD_API_KEY. Invalid or missing keys result in a 401 Unauthorized response.

2. Handler Layer

Gin handlers parse and validate incoming JSON payloads. They extract transaction data (amount, currency, IP, device, location) and delegate to the service layer.

3. Risk Engine

The core scoring engine applies weighted rules to calculate a base risk score (0-100). Rules are evaluated in parallel where possible.

4. AI Escalation Gate

If the base score is ≥40 (MEDIUM risk threshold), the transaction is escalated to the AI service for enhanced analysis.

5. Response Assembly

Results are aggregated, formatted as JSON, and returned with appropriate HTTP status codes.

Risk Engine

The risk engine uses a weighted scoring system based on the following factors:

Risk Thresholds

• LOW (0-39): Approve automatically
• MEDIUM (40-69): AI analysis triggered, manual review recommended
• HIGH (70-100): Block automatically, AI analysis for audit trail

AI Integration

Asguard uses Groq's Llama-3.3-70b-versatile model for enhanced risk analysis. The AI service constructs detailed prompts including:

• Transaction context (amount, currency, location)
• Rule-based score and triggered factors
• Historical patterns (if available)
• Strict output formatting instructions

AI Prompt Structure

You are a fraud detection analyst. Analyze this transaction:
- Amount: $250,000 USD
- Location: Lagos, Nigeria (User typically transacts from London, UK)
- Device: New device fingerprint
- IP: 102.88.XX.XX (Residential ISP)

Rule-based score: 41/100 (MEDIUM)
Triggered rules: High amount, Foreign location, New device

Provide your assessment in this exact format:
RECOMMENDATION: [APPROVE/REVIEW/BLOCK]
CONFIDENCE: [0.0-1.0]
FRAUD_PROBABILITY: [0.0-1.0]
REASONING: [Brief explanation]

API Reference

Authentication

All API endpoints (except health check) require authentication via the x-api-key header.

curl -H "x-api-key: your-api-key" \
     -H "Content-Type: application/json" \
     http://localhost:8081/analyze

Security Headers

Asguard implements several security headers by default:

• X-Content-Type-Options: nosniff
• X-Frame-Options: DENY
• X-XSS-Protection: 1; mode=block
• Strict-Transport-Security: max-age=31536000 (in production)

Endpoints

Health Check

Verify system status. No authentication required.

GET /health

Response:

{
  "status": "asguard health running",
  "version": "1.0.0",
  "timestamp": "2026-03-02T10:00:00Z",
  "uptime": "72h15m30s"
}

Analyze Transaction

Submit a transaction for risk analysis.

POST /analyze

Request Headers:

Request/Response Schemas

Analyze Request

{
  "user_id": "user_12345",           // string, required
  "transaction_id": "txn_67890",     // string, required, unique
  "amount": 250000.00,               // number, required, > 0
  "currency": "USD",                 // string, required, ISO 4217
  "ip_address": "192.168.1.1",       // string, optional, IPv4/IPv6
  "device_id": "device_abc123",      // string, optional
  "location": "Lagos, Nigeria",      // string, optional
  "timestamp": "2026-03-02T10:00:00Z" // string, optional, ISO 8601
}

Analyze Response

{
  "transaction_id": "txn_67890",
  "risk_score": 41,
  "risk_level": "MEDIUM",
  "reasons": [
    "High transaction amount (>100k)",
    "Foreign currency transaction (USD)",
    "Unusual geolocation pattern"
  ],
  "ai_triggered": true,
  "ai_confidence": 0.85,
  "ai_recommendation": "REVIEW",
  "ai_fraud_probability": 0.45,
  "ai_summary": "Large USD transaction from Lagos warrants manual review",
  "processing_time_ms": 142,
  "timestamp": "2026-03-02T10:00:00Z"
}

Error Responses

Facial Verification & Face Service

The face service provides the biometric component of Asguard. Although it can be run independently of the backend, the two are often deployed together via docker-compose to enable combined fraud and identity workflows.

Setup

• Ensure the three dlib model files are present under ./models/ at the project root.
• Define environment variables:

  MODELS_PATH=./models
  API_KEYS=dev1,dev2
  PORT=8082

• Start the service manually or with Docker:

  cd asguard-face
  MODELS_PATH=../../models API_KEYS=dev1 PORT=8082 go run main.go

Typical Use Cases

Common integration patterns include:

1. Enrollment. Capture a user selfie, POST to /v1/analyze, and store the returned embedding alongside their account.
2. Authentication/Validation. On each login or sensitive transaction, capture a fresh photo and POST to /v1/compare along with the stored reference embedding. Use the boolean match and confidence to make a decision.

API Details

Health Check

GET /health

No authentication required; returns service status.

Extract Embedding

POST /v1/analyze
Authorization: Bearer <API_KEY>
Content-Type: application/json

{
  "image": "<base64>",
  "quality_checks": true
}

Response includes embedding array, quality metrics and any warnings.

Compare Faces

POST /v1/compare
Authorization: Bearer <API_KEY>
Content-Type: application/json

{
  "probe_image": "<base64>",
  "reference_embedding": [...],
  "threshold": 0.6
}

Response contains match, confidence, distance, and the threshold used.

Best Practices

• Always enable quality_checks to filter out poor captures.
• Store embeddings securely and treat them as sensitive biometric data.
• Use TLS for all service communication and rotate API keys regularly.
• Adjust the comparison threshold according to your tolerance for false positives/negatives; 0.6 is the default.

Docker Compose

The existing docker-compose.yml at the root already includes both services. When you run docker compose up --build, it mounts the ./models/ volume into the face container and binds ports 8081 (backend) and 8082 (face).

Deployment

Docker Deployment

Asguard includes Docker configurations for both development and production environments.

Development Mode

The development configuration includes hot-reloading via volume mounts:

cd backend
docker-compose -f docker-compose.dev.yml up --build

Production Build

docker build -t asguard:latest .
docker run -d \
  --name asguard \
  -p 8081:8081 \
  -e ASGUARD_API_KEY=${ASGUARD_API_KEY} \
  -e GROQ_API_KEY=${GROQ_API_KEY} \
  -e ENV=production \
  asguard:latest

Docker Compose (Production)

version: '3.8'
services:
  asguard:
    build: .
    ports:
      - "8081:8081"
    environment:
      - ASGUARD_API_KEY=${ASGUARD_API_KEY}
      - GROQ_API_KEY=${GROQ_API_KEY}
      - PORT=8081
      - ENV=production
      - LOG_LEVEL=info
    restart: unless-stopped
    healthcheck:
      test: ["CMD", "curl", "-f", "http://localhost:8081/health"]
      interval: 30s
      timeout: 10s
      retries: 3
    deploy:
      resources:
        limits:
          cpus: '2'
          memory: 512M
        reservations:
          cpus: '0.5'
          memory: 128M

Production Checklist

• Use strong, randomly generated API keys (minimum 32 characters)
• Enable TLS/SSL termination (via reverse proxy or load balancer)
• Configure rate limiting (recommended: 100 req/min per client)
• Set up log aggregation (structured JSON logging enabled by default)
• Monitor AI service latency and implement circuit breakers
• Regular security audits of rule configurations

Monitoring & Observability

Asguard exposes Prometheus-compatible metrics at /metrics (if enabled):

• asguard_requests_total - Total requests by endpoint and status
• asguard_request_duration_seconds - Request latency histogram
• asguard_risk_scores - Distribution of risk scores
• asguard_ai_requests_total - AI service call count
• asguard_ai_latency_seconds - AI response time

Development

Testing

Run the test suite:

go test ./... -v

Run with coverage:

go test ./... -coverprofile=coverage.out
go tool cover -html=coverage.out

Integration Tests

Integration tests require a valid Groq API key:

GROQ_API_KEY=test-key go test ./... -tags=integration

Contributing

We welcome contributions. Please follow these guidelines:

1. Fork the repository and create a feature branch (git checkout -b feature/amazing-feature)
2. Ensure your code follows Go conventions (gofmt, golint)
3. Write tests for new functionality
4. Update documentation for API changes
5. Commit using conventional commits format
6. Open a Pull Request with a detailed description

Code Style

• Use gofmt for formatting
• Follow Effective Go guidelines
• Document all exported functions and types
• Keep functions focused and under 50 lines where possible
